HiPerLip® - PTFE Rotary Lip Seal with Metal Casing

PTFE Rotary Lip Seal | Type KS

Teflon rotary lip seal with dual lip seal with primary lip energized with spring.

CATALOGUE

PTFE Rotary Lip Seal | Type S2 PTFE Rotary Lip Seal | Type SB

Suitable for medium speed application
Suitable for low to medium pressure
Suitable when abrasive media is used

Application Range

Speed: ≤ 8 m/s
Pressure: ≤ 35 bar
Temperature: -150°C ~ 225°C

Common Applications

Petrochemical Industry

Oil & Gas Industry

Infrastructure Industry

Optional Design

Guidelines for the Selection of Special Sizes

Unit: mm

Shaft diameter	Outside diameter	Casing width
8	22	7
8	24	7
8	26	7
9	22	7
9	24	7
9	26	7
10	22	7
10	24	7
10	26	7
12	22	7
12	24	7
12	26	7
12	28	7
12	30	7
14	24	7
14	28	7
14	30	7
14	35	7
15	26	7
15	30	7
15	32	7
15	35	7
16	28	7
16	30	7
16	35	7
17	28	7
17	30	7
17	32	7
17	35	7
17	40	7
18	30	7
18	32	7
18	35	7
18	40	7
20	30	7
20	32	7
20	35	7
20	40	7
20	47	7
22	32	7
22	35	7
22	40	7
22	47	7
24	35	7
24	37	7
24	40	7
24	47	7
25	35	7
25	40	7
25	42	7
25	47	7
25	52	7
26	37	7
26	42	7
26	47	7
28	40	7
28	47	7
28	52	7
30	40	7
30	42	7
30	45	7
30	47	7
30	50	7
30	52	7
32	45	8
32	47	8
32	52	8
35	47	8
35	50	8
35	52	8
35	55	8
35	62	8
38	55	8
38	58	8
38	62	8
40	52	8
40	55	8
40	60	8
40	62	8
42	55	8
42	60	8
42	62	8
42	72	8
45	60	8
45	62	8
45	65	8
48	65	8
50	68	8
50	72	8
52	72	8
55	72	8
55	80	8
60	75	8
60	80	8
60	85	8
62	80	8
65	85	8
65	90	10
65	100	10
68	90	10
68	100	10
70	90	10
70	95	10
70	100	10
75	95	10
75	100	10
80	100	10
80	110	10
85	110	10
85	120	12
90	110	10
90	120	12
95	120	12
100	120	12
100	125	12
100	130	12
105	130	12
110	130	12
110	140	12
115	140	12
115	150	12
120	150	12
125	150	12
125	160	12
130	160	12
Further sizes on request

Material code	Reference	Compound	Color	Temp. °C (MIN.)	Temp. °C (MAX.)	Application	Characteristics	Products
1	01T	VIRGIN PTFE	WHITE	-190	220	• CHEMICAL INDUSTRY • SEMI-CONDUCTOR • FOOD INDUSTRY	• HIGH CHEMICAL RESISTANCE • LOW COEFFICIENT OF FRICTION	• BACK-UP RINGS • HIPERSEALS
2	03T	PTFE + CARBON + GRAPHITE	BLACK	-190	315	• HIGH MECHANICAL STRESS • WATER/OIL HYDRAULICS • ROTARY SEALING	• HIGH WEAR RESISTANCE • CREEP RESISTANCE	• GLIDE RINGS • PNEUMATIC GUIDANCE TAPE • BACK-UP RINGS • HIPERSEAL
3	02T	PTFE + BRONZE	GREEN	-156	260	• HIGH MECHANICAL STRESS • HYDRAULIC APPLICATIONS	• OUTSTANDING WEAR RESISTANCE • EXTRUSION RESISTANCE • CREEP RESISTANCE	• GLIDE RINGS • HYDRAULIC GUIDANCE TAPE • BACK-UP RINGS
4	UPE	UHMW-PE	WHITE	-200	80	• HYDRAULIC APPLICATIONS	• OUTSTANDING WEAR RESISTANCE • GOOD OXIDATION RESISTANCE • OUTSTANDING EXTRUSION RESISTANCE • OUTSTANDING SEALING UNDER LOW PRESSURE	• BACK-UP RINGS • SPRING ENERGIZED SEALS
4G	4G	ULTRAGOLD®	YELLOW	CRYOGENIC	93	• HYDRAULIC APPLICATIONS	• OUTSTANDING WEAR RESISTANCE • SELF-LUBRICATING PROPERITIES • OUTSTANDING EXTRUSION RESISTANCE • OUTSTANDING PERFORMANCE UNDER CRYOGENIC APPLICATION	• HIPERSEALS
5	05T	PTFE + CARBON FIBER	GREY	-260	310	• WATER HYDRAULICS • SHORT STROKES WITH HIGH OPERATION FREQUENCY	• VERY GOOD WEAR RESISTANCE PROPERTIES IN WATER • EXCELLENT COMPRESSIVE STRENGTHS • DYNAMIC APPLICATIONS AT HIGH SPEED	• GLIDE RINGS • HIPERSEALS
6	06T	PTFE + GLASS FIBER	WHITE	-190	290	• MEDIUM-DUTY HYDRAULIC APPLICATIONS	• HIGH CHEMICAL RESISTANCE • HIGH CREEP RESISTANCE • ELECTRICAL PROPERTIE LIKE VIRGIN PTFE	• GLIDE RINGS • BACK-UP RINGS • GUIDE RINGS • GASKETS
7	07T	PTFE + EKONOL	BEIGE	-260	320	• MEDIUM MECHANICAL STRESS • SOFTER SEALING SURFACES • ROTARY SEALING	• LIMITED CHEMICAL RESISTANCE • LIMITED USE IN HOT WATER	• HIPERSEALS • ROTARY GLIDE RINGS • LIP SEALS
8	08T	PTFE + E-CARBON	BLACK	-190	290	• MEDIUM MECHANICAL STRESS • HARD SEALING SURFACES • WATER/OIL EMULSIONS	• CHEMICAL RESISTANCE LIMITED BY CARBON	• HIPERSEALS
9	09T	PTFE + GRAPHITE	DARK GREY	-190	260	• LOW MECHANICAL STRESS • SOFT SEALING SURFACES	• CHEMICAL RESISTANCE LIMITED GRAPHITE	• HIPERSEALS
10	10T	PTFE + GLASS FIBER + MOS2	GREY	-190	260	• MEDIUM MECHANICAL STRESS • MEDIUM-DUTY HYDRAULIC APPLICATIONS	• HIGH CREEP STRENTH • HIGH CHEMICAL RESISTANCE • OUTSTANDING WEAR RESISTANCE • ELECTRICAL PROPERTIES LIKE VIRGIN PTFE	• HIPERSEALS • ROTARY SEALS • BACK-UP RINGS
PE	01K	PEEK	BEIGE/ BLACK	-73	316	• HYDRAULIC APPLICATIONS	• GOOD CHEMICAL RESISTANCE • GOOD WEAR RESISTANCE • HIGH MAXIMUM USE TEMPERATURE • LOW FLAMMABILITY • EXCELLENT ELECTRICAL PROPERTIES • GOOD RADIATION RESISTANCE	• BACK-UP RINGS • HIPERSEALS

Code	Material	Application
METAL CASING
1	Carbon steel	Low cost Standard material for metal case General application without corrosion issue
2	Stainless steel 304	General application under corrosive environment
3	Stainless steel 316	General application for corrosive media
GASKET
1	NBR	Standard material for temperature range from -40 to 100℃
2	FPM(Viton®)	Chemical and heat resistant material Temperature range from -20°C to 200°C
